Galaxy® XL

producticon1
AUTOMATED INCLUSION MAPPING OF LARGER STONES

SARINE Galaxy® XL系统是一款全球领先的大型毛坯原石包裹体测绘设备,适用于高达180克拉的毛坯原石。

producticon2
Key Benefits

  • Handles all types of inclusions whether transparent or black - piques, cracks (“gletzes”), bubbles, clouds, etc.
  • Detects inclusions up to VS classification
  • Scans most diamonds including, frosted and even slightly coated, regardless of level of impurities
  • Scans diamonds up to ~ 180ct.
  • Generates an easily understandable 3D model of the rough diamond with all inclusions clearly mapped
  • Productivity dictated by stone size: 1-2 hours per stone, regardless of level of impurities
  • Together with Advisor - Precise rough planning based on internal features without any human errors
  • Together with Advisor - Advanced optimization of polished diamonds taking into consideration all relevant information – Carat, Clarity and Cut
  • Includes Stone Management System to efficiently control the entire process

producticon3
Technical Specifications

  • Stone sizes
    H - Up to 34mm
    W - Up to 28mm
  • Stone weight
    Up to ~180ct.
  • Productivity
    Dictated by stone size: 1-2 hours per stone
  • Detection ability (inclusion type)
    VS2 to I3
  • Weight (machine only)
    180kg (400 Ibs)
  • Power Consumption
    1.0 kW/h

producticon4
